Vertical Centrifugal Dewatering Machine
Laizhou Yuening Machinery designs the Vertical Centrifugal Dewatering Machine as a high-efficiency drying solution for plastic recycling lines. Built to handle a wide range of rigid and semi-rigid plastic scraps, including PET bottle flakes, PP/PE crushed plastics, and ABS hard pieces, this machine is a key component in plastic crushing, washing, and drying workflows. Its vertical structure and centrifugal working principle make it ideal for continuous, automatic drying without the need for manual material recovery.
Features
Laizhou Yuening Machinery designs the Vertical Centrifugal Dewatering Machine as a high-efficiency drying solution for plastic recycling lines. Built to handle a wide range of rigid and semi-rigid plastic scraps, including PET bottle flakes, PP/PE crushed plastics, and ABS hard pieces, this machine is a key component in plastic crushing, washing, and drying workflows. Its vertical structure and centrifugal working principle make it ideal for continuous, automatic drying without the need for manual material recovery.
The Vertical Centrifugal Dewatering Machine operates at a consistent 1000 r/min, using high-speed rotation to generate strong centrifugal force that removes surface moisture from plastic flakes. It runs on standard 380V industrial power and is available in multiple models to match different production scales: from the Type530 with a 400–500 kg/h capacity to the Type1000 with a maximum output of 2000–3000 kg/h. The internal screen is made of durable 201 or 304 stainless steel, ensuring reliable performance even with abrasive materials.
Constructed with a heavy-duty steel frame, the machine is built to withstand long-term, continuous use. The Type530 model weighs 200kg, while the larger Type1000 reaches 900kg, reflecting the robust build quality across the entire range. Its compact vertical footprint allows for easy integration into existing plastic washing lines, making it a practical choice for both new and retrofitted recycling facilities. The machine's simple operation and low maintenance requirements help keep production running smoothly, with minimal downtime.
Beyond basic dewatering, the Vertical Centrifugal Dewatering Machine also aids in material cleaning. As plastic flakes spin against the internal screen, loose dirt, sand, and residual contaminants are removed, improving the overall quality of the dried material. It works seamlessly with both floating materials like PP/PE and heavier crushed plastics, making it a versatile solution for diverse recycling applications.

Parameters
|
Model |
Type530 |
Type630 |
Type820 |
Type1000 |
|
Boundary dimension(mm) |
800*800*2000mm |
1000*1000*2400mm |
1400*1400*2600mm |
1700*1700*3000mm |
|
Internal network height(h) |
1200mm |
1600mm |
1800mm |
2000mm |
|
Internal network material |
201 stainless steel |
201 stainless steel |
201 stainless steel |
304 stainless steel |
|
Weight(kg) |
200kg |
300kg |
500kg |
900kg |
|
Power(kw) |
7.5kw |
15kw |
22kw |
30kw |
|
Voltage(V) |
380v |
380v |
380v |
380v |
|
Rotate speed(r/min) |
1000r/min |
1000r/min |
1000r/min |
1000r/min |
|
Maximum Capacity(kg/h) |
400-500kg/h |
500-1000kg/h |
1000-2000kg/h |
2000-3000kg/h |
Key Features
- It delivers efficient centrifugal dewatering for plastic flakes, supporting direct granulation and further processing.
- The vertical design saves floor space while ensuring high throughput, with capacities up to 3000 kg/h for large-scale operations.
- Durable stainless steel screens (201/304) provide long service life and easy maintenance.
- The automatic operation eliminates the need for manual material recovery, streamlining the production workflow.
- Versatile compatibility with PET, PP, PE, and ABS materials makes it suitable for diverse plastic recycling lines.
